Made for manager level users in the office |
|
|
|
3.2 inch TFT color display enrich your colorful life |
|
|
|
Top level voice quality |
|
|
|
Powerful BLF+BLA function |
|
|
|
Batch configure and deploy the phones with tools Under Windows OS |
|
|
|
Dual core CPU is the guarantee of high quality IP phone |
|
|
|
|
|
|
Phone functions Phone functions:3 ways to make or receive call – handset/headset/hand-free speaker; Support caller ID , auto answer , DND and call reject; Support speed dial , redial , mute and call holding; Support point to point calls via IP address and SIP URL; Support 3 ways conference call; Support call transfer( blinded transfer , attendant transfer and semi-attendant transfer); Support call forward ( always forward , busy forward or no answer forward); Support hotline and flexible dial plan configuration; IP PBX function: BLF ( busy line field) , BLA (line sharing) , BLF list Anonymous Call, Anonymous Call Rejection; Synchronization Message Waiting Indicator (MWI); Voicemail , call recording; Call on hold , call pick up; Paging and intercom; |
Hardware Specification 2*400MHZ dual core MIPS processor(R3G\R3GW);2*263MHZ dual core MIPS processor(R3\R3W); 3.2 inch 400*240 WQVGA 16,670,000 color display; 43 keys including 12 programmable keys; Dual RJ45 10/100Mhz Ports（R3\R3W）； Dual RJ45 10/100/1000Mhz Ports（R3G\R3GW）； 2 RJ9 ports ( for handset and headset); 1 RJ45 port for extension modules; Power adapter AC 90-240V , DC 5V; Standby power consumption <1W , working power consumption 2.5W; Support PoE ( power over ethernet); Support rainbow E and rainbow T extension modules; Working temperature : -10 ℃– 50 ℃; Working humid : 10%-95% |
Network features Support SIP V1(RFC2543), V2(RFC3261);Support backup server; Support proxy server and point to point connection; Support IP/DHCP/PPPoE dial; Support FTP/DHCP/PPPoE client; Support Telnet/HTTP/HTTPS service; Support SNTP protocol; Support DNS SRV（RFC3263; Support DNS client and buil-in NAT/DHCP service; Support STUN; Support 3 DTMF ways,RFC2833 and SIP INFO; Support router and bride mode; Logout on web GUI; |
Software features UI and WEB Support multiple language;User friendly UI and WEB design; Support contacts image display; Support 400 contacts in phone book and 400 call history record; Support dial assistant , match the number in smart ways; Support black list; Auto adjusted background light ; Adjustable level of background light brigntness; Press for a few seconds to edit programmable keys; |
|
Voice feature Support HD voice codec L16G and G.722;Support G.711a/u,G.726，G.729a/b，G.723,iLBC codes; Support VAD(Voice Activity Detector) and CNG(conformation noise gain); Support AJB ( auto Jit buffer) , AEC ( voice echo canceller) AGC ( voice gain control); 10 broadband rings and 2 customized rights by users; |
Management Support 3 ways to manage the phones : Web GUI , phone keyboard and auto configuration in FTP/TFTP/HTTP/HTTPS/PnP;Configuration wizard on web UI; Support SNMP; |
Security Support VLAN;Support L2TP VPN; Support 802.1X; Support 2 different access levels- admin and user; Support SRTP and HTTPS protocol ( client/server); |
Package Dimension of single unit （21.8 x 17.6 x 12.9）;Weight :1.3Kg; Packing size （31.0x 20.7 x 7.5）cm; Preserve temperature -40 - -70℃; Preserve humid level: 10-95%; |
|
Certification |
|||
|
|||
Models |
| R3 Models | PoE | Wifi | Megabit | Gigabit |
|
R3
|
Y | N | Y | N |
| R3G | Y | N | N | Y |
